The STEMAT-JANSEN Gate Valve have a wedge that moves linearly and perpendicularly to the flows at the seatings rings level. The wedges can be monobloc or flexible. The outside sealing is obtained with a gland- packing The Gate Valve are here to let or to stop any liquid medium or gas.
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen010-copy-300x300.jpg)
Gate valve – GG25 cast iron – inside stem – brass seat – Fig 010/28 PN10
Material :
Cast iron
Type :
DIN standard Inside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/fig-011-300x300.jpg)
Gate valve – GG25 cast iron – inside stem – stainless steel seat – Fig 011/34 PN10
Material :
Cast iron
Type :
DIN standard Inside stem Flat body
![](https://www.stematjansen.com/wp-content/uploads/2013/12/011-34-PN10-ME-300x300.jpg)
Electrically actuated gate valve – GG25 cast iron – inside stem – stainless steel seat – Fig 011/34 PN10 EA
Material :
Cast iron
Type :
DIN standard Inside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen012-copy-300x300.jpg)
Gate valve – GG25 cast iron – outside stem – brass seat – Fig 012/30 PN10
Material :
Cast iron
Type :
Flat body DIN standard Outside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen012-copy-300x300.jpg)
Gate valve – GGG40 ductile iron – outside stem – bronze seats – Fig. 012/30 PN 16
Material :
Nodular cast iron
Type :
Outside stem Flat body DIN standard
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen012-copy-300x300.jpg)
Gate valve – GG25 cast iron – outside stem – stainless steel Seat – Fig. 013/31 PN10
Material :
Cast iron
Type :
Flat body DIN standard Outside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen012-copy-300x300.jpg)
Gate valve – GGG40 ductile iron – outside stem – stainless steel seats – Fig. 013/31 PN16
Material :
Nodular cast iron
Type :
Flat body DIN standard Outside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen012-copy-300x300.jpg)
Gate valve – NFE standard – GG25 cast iron – outside stem – bronze seat – Fig. 014/24 PN10
Material :
Cast iron
Type :
Outside stem French standard Flat body
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen012-copy-300x300.jpg)
Gate valve – NFE standard – GGG50 ductile iron – outside stem – bronze seat – Fig. 015/25 PN16
Material :
Nodular cast iron
Type :
French standard Flat body Outside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen012-copy-300x300.jpg)
Gate valve – NFE standard – GGG50 ductile iron – outside stem – stainless steel seat – Fig. 016/26 PN16
Material :
Nodular cast iron
Type :
Flat body Outside stem French standard
![](https://www.stematjansen.com/wp-content/uploads/2013/04/fig-017-300x300.jpg)
Gate valve – NFE standard – GG25 cast iron – inside stem – bronze seat – Fig. 017/22 PN10
Material :
Cast iron
Type :
Flat body Inside stem French standard
![](https://www.stematjansen.com/wp-content/uploads/2013/04/fig-018-300x300.jpg)
Gate valve – NFE standard – GG25 cast iron – inside stem – stainless steel seat – Fig. 018/23 PN10
Material :
Cast iron
Type :
Flat body Inside stem French standard
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen020-copy-300x300.jpg)
Gate valve – oval body – GG25 cast iron – inside stem – brasse seat – Fig. 020/32 PN16
Material :
Nodular cast iron Cast iron
Type :
Oval body DIN standard Inside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/fig-021-300x300.jpg)
Gate valve – oval body – GG25 cast iron – inside stem – stainless steel seat – Fig. 021/33 PN16
Material :
Nodular cast iron Cast iron
Type :
Oval body DIN standard Inside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/fig-021-300x300.jpg)
Gate valve – oval body – GG25 cast iron – inside stem – stainless steel seat – Fig. 021/33 PN10
Material :
Cast iron
Type :
Oval body Inside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/12/021-33-PN10-RM-300x300.jpg)
Gate valve with manual gearbox – oval body – GG25 cast iron – inside stem – stainless steel seat – Fig. 021/33 PN10 MGB
Material :
Cast iron
Type :
Oval body
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen022-copy-300x300.jpg)
Gate valve – flat body – GGG50 ductile iron – EPDM coated wedge – Fig. 022/54 PN16 ACS
Material :
Nodular cast iron Cast iron
Type :
DIN standard Inside stem ACS Flat body
![](https://www.stematjansen.com/wp-content/uploads/2013/11/Image-4-300x300.jpg)
Electrically actuated gate valve – flat body – GGG50 ductile iron – EPDM coated wedge – Fig. 022/54 ME PN16 ACS
Material :
Nodular cast iron
Type :
Flat body DIN standard ACS
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen022-copy-300x300.jpg)
Gate valve – flat body – GGG50 ductile iron – NBR coated wedge – Fig. 022/54 PN16 NBR
Material :
Nodular cast iron Cast iron
Type :
DIN standard Inside stem Flat body
![](https://www.stematjansen.com/wp-content/uploads/2013/04/fig-023-300x300.jpg)
Gate valve – flat body – GGG50 ductile iron – EPDM coated wedge – Fig. 023/55 PN25 ACS
Material :
Nodular cast iron Cast iron
Type :
DIN standard Inside stem ACS Flat body
![](https://www.stematjansen.com/wp-content/uploads/2013/11/Image-4-300x300.jpg)
Electrically actuated gate valve – flat body – GGG50 ductile iron – EPDM coated wedge – Fig. 023/55 PN25 ACS
Material :
Nodular cast iron
Type :
Flat body DIN standard ACS
![](https://www.stematjansen.com/wp-content/uploads/2013/04/fig-023-300x300.jpg)
Gate valve – flat body – GGG50 ductile iron – NBR coated wedge – Fig. 023/55 PN25 NBR
Material :
Nodular cast iron Cast iron
Type :
Flat body DIN standard Inside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/fig-027-300x300.jpg)
Gate valve – oval body – GGG50 ductile iron – EPDM coated wedge – Fig. 027/58 PN16 ACS
Material :
Nodular cast iron
Type :
Oval body DIN standard Inside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/09/VanneStematJansen030-copy-624x624-300x300.jpg)
Gate valve – oval body – cast steel – inside stem – stainless steel seat – Fig. 030/72 PN16
Material :
Cast steel
Type :
Oval body Inside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/09/VanneStematJansen030-copy2-624x624-300x300.jpg)
Gate valve – oval body – cast steel – inside stem – stainless steel seat – Fig. 030/72 PN25
Material :
Cast steel
Type :
DIN standard Inside stem Oval body
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen031-032-036-copy-300x300.jpg)
Gate valve – oval body – cast steel – outside stem – stainless steel seat – Fig. 031/73 PN16
Material :
Cast steel
Type :
Outside stem Oval body DIN standard
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen031-032-036-copy-300x300.jpg)
Gate valve – oval body – cast steel – outside stem – stainless steel seat – Fig. 032/75 PN25
Material :
Cast steel
Type :
DIN standard Outside stem Oval body
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen031-032-036-copy-300x300.jpg)
Gate valve – oval body – cast steel – outside stem – stainless steel seat – Fig. 032/75 PN25 ACS
Material :
Cast steel
Type :
DIN standard Outside stem ACS Oval body
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen033-copy-300x300.jpg)
Gate valve – cast steel – outside stem – flexible wedge – Fig. 033/78 PN40
Material :
Cast steel
Type :
DIN standard Outside stem Oval body
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen031-032-036-bleu-copy-300x300.jpg)
Gate valve – cast steel with epoxy coating – outside stem – flexible wedge – Fig. 033/78 PN40 ACS
Material :
Cast steel
Type :
Oval body DIN standard Outside stem ACS
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen035-copy-300x300.jpg)
Gate valve – cast steel – outside stem – stainless steel seat – Fig. 035/79 PN63
Material :
Cast steel
Type :
Outside stem Oval body DIN standard
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen031-032-036-bleu-copy-300x300.jpg)
Gate valve – cast steel with epoxy coating – outside stem – stainless steel seat – Fig. 035/79 PN63 ACS
Material :
Cast steel
Type :
Oval body DIN standard Outside stem ACS
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen031-032-036-copy-300x300.jpg)
Gate valve – cast steel – outside stem – stainless steel seat – Fig. 036/80 PN100
Material :
Cast steel
Type :
Oval body DIN standard Outside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen031-032-036-bleu-copy-300x300.jpg)
Gate valve – cast steel with epoxy coating – outside stem – stainless steel seat – Fig. 036/80 PN100 ACS
Material :
Cast steel
Type :
Outside stem ACS Oval body DIN standard
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen040-copy-300x300.jpg)
ANSI Gate valve – cast steel – seat Trim 8 – Fig. 040/65 PN20 ASA 150lbs
Material :
Cast steel
Type :
Oval body ASA standard Outside stem
![](https://www.stematjansen.com/wp-content/uploads/2013/04/VanneStematJansen041-copy-300x300.jpg)
ANSI Gate valve – cast steel – seat Trim 8 – Fig. 041/66 PN50 ASA 300lbs
Material :
Cast steel
Type :
Outside stem Oval body ASA standard
![](https://www.stematjansen.com/wp-content/uploads/2013/04/fig-042-300x300.jpg)
ANSI Gate valve – cast steel – seat Trim 8 – Fig. 042/67 PN100 ASA 600lbs
Material :
Cast steel
Type :
Oval body ASA standard Outside stem
